Camera
- Image Sensor8 MP CMOS
- Signal SystemPAL/NTSC
- Resolution3840 (H) Ć 2160 (V)
- Frame RateTVI: 8 MP @ 12.5 fps/15 fps, 3K @ 20 fps, 1080P @ 25 fps/30 fps
- Min. Illumination0.0005 Lux@(F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/12.5 s to 1/50,000 s;NTSC: 1/15 s to 1/50,000 s
- Lens2.8 mm, 3.6 mm fixed focal lens
- Field Of View
2.8 mm, horizontal FOV: 110Ā°, vertical FOV: 59Ā°, diagonal FOV: 131Ā°
3.6 mm, horizontal FOV: 93Ā°, vertical FOV: 48Ā°, diagonal FOV: 113Ā°
- Lens MountM16
- Light AlarmSolid Light Alarm (White Light)
- Day & Night24/7 Color Imaging
- WDR (Wide Dynamic Range)ā„130 dB
- Angle AdjustmentPan: 0Ā° to 360Ā°, Tilt: 0Ā° to 180Ā°, Rotation: 0Ā° to 360Ā°
- White LightAuto/Off
- Image ModeSTD/HIGH-SAT/HIGHLIGHT
- AGCYes
- Day/Night ModeColor
- White BalanceAuto/Manual
- AE (Auto Exposure) ModeWDR;BLC;HLC;Global;HLS
- Privacy Mask4 programmable privacy masks
- Motion Detection4 programmable motion areas
- Noise Reduction3D DNR/2D DNR
- LanguageEnglish
- FunctionSharpness;Mirror;Brightness;Anti-Banding;Smart Light;Contrast
Interface
- Video Output1 HD analog output
- General
- Operating Conditions-40Ā°C to 50Ā°C (-40Ā°F to 130Ā°F), Humidity: 90% or less (non-condensing)
- Power Supply
12 VDC Ā± 25%/PoC.at
*You are recommended to use one power adapter for one camera, and use 2-pin power supply for long-distance power supply.
- ConsumptionMax. 5.1 W
- Protection LevelIP67
- MaterialMain body: Metal, Enclosure: Plastic
- White Light RangeUp to 40 m
- CommunicationHIKVISION-C
- Dimension194.2 mm Ć 78 mm Ć 74.5 mm (7.65″ Ć 3.07″ Ć 2.93″)
- Approx. 350 g (0.77 lb.)
